Metric Round Head Screw:
| COLOR CODES MUST BE INCLUDED WITH THE ITEM NUMBER WHEN ORDERING. | ||
|---|---|---|
| B - Black | RD - Red | WT - White |
| BL - Blue | GR - Green | |
| Item Number | Screw Size | Screw Length | Head Dia. |
| 29M30050R008B | M3 | 8MM | 0.375 |
| 29M30050R008BL | M3 | 8MM | 0.375 |
| 29M30050R008GR | M3 | 8MM | 0.375 |
| 29M30050R008RD | M3 | 8MM | 0.375 |
| 29M30050R008WT | M3 | 8MM | 0.375 |
| 29M30050R010B | M3 | 10MM | 0.375 |
| 29M30050R010BL | M3 | 10MM | 0.375 |
| 29M30050R010GR | M3 | 10MM | 0.375 |
| 29M30050R010RD | M3 | 10MM | 0.375 |
| 29M30050R010WT | M3 | 10MM | 0.375 |
| 29M30050R012B | M3 | 12MM | 0.375 |
| 29M30050R012BL | M3 | 12MM | 0.375 |
| 29M30050R012GR | M3 | 12MM | 0.375 |
| 29M30050R012RD | M3 | 12MM | 0.375 |
| 29M30050R012WT | M3 | 12MM | 0.375 |
| 29M30050R016B | M3 | 16MM | 0.375 |
| 29M30050R016BL | M3 | 16MM | 0.375 |
| 29M30050R016GR | M3 | 16MM | 0.375 |
| 29M30050R016RD | M3 | 16MM | 0.375 |
| 29M30050R016WT | M3 | 16MM | 0.375 |
| 29M40070R010B | M4 | 10MM | 0.5 |
| 29M40070R010BL | M4 | 10MM | 0.5 |
| 29M40070R010GR | M4 | 10MM | 0.5 |
| 29M40070R010RD | M4 | 10MM | 0.5 |
| 29M40070R010WT | M4 | 10MM | 0.5 |
| Item Number | Screw Size | Screw Length | Head Dia. |
| 29M40070R012B | M4 | 12MM | 0.5 |
| 29M40070R012BL | M4 | 12MM | 0.5 |
| 29M40070R012GR | M4 | 12MM | 0.5 |
| 29M40070R012RD | M4 | 12MM | 0.5 |
| 29M40070R012WT | M4 | 12MM | 0.5 |
| 29M40070R016B | M4 | 16MM | 0.5 |
| 29M40070R016BL | M4 | 16MM | 0.5 |
| 29M40070R016GR | M4 | 16MM | 0.5 |
| 29M40070R016RD | M4 | 16MM | 0.5 |
| 29M40070R016WT | M4 | 16MM | 0.5 |
| 29M40070R020B | M4 | 20MM | 0.5 |
| 29M40070R020BL | M4 | 20MM | 0.5 |
| 29M40070R020GR | M4 | 20MM | 0.5 |
| 29M40070R020RD | M4 | 20MM | 0.5 |
| 29M40070R020WT | M4 | 20MM | 0.5 |
| 29M40070R025B | M4 | 25MM | 0.5 |
| 29M40070R025BL | M4 | 25MM | 0.5 |
| 29M40070R025GR | M4 | 25MM | 0.5 |
| 29M40070R025RD | M4 | 25MM | 0.5 |
| 29M40070R025WT | M4 | 25MM | 0.5 |
| 29M50080R012B | M5 | 12MM | 0.625 |
| 29M50080R012BL | M5 | 12MM | 0.625 |
| 29M50080R012GR | M5 | 12MM | 0.625 |
| 29M50080R012RD | M5 | 12MM | 0.625 |
| 29M50080R012WT | M5 | 12MM | 0.625 |
| Item Number | Screw Size | Screw Length | Head Dia. |
| 29M50080R016B | M5 | 16MM | 0.625 |
| 29M50080R016BL | M5 | 16MM | 0.625 |
| 29M50080R016GR | M5 | 16MM | 0.625 |
| 29M50080R016RD | M5 | 16MM | 0.625 |
| 29M50080R016WT | M5 | 16MM | 0.625 |
| 29M50080R020B | M5 | 20MM | 0.625 |
| 29M50080R020BL | M5 | 20MM | 0.625 |
| 29M50080R020GR | M5 | 20MM | 0.625 |
| 29M50080R020RD | M5 | 20MM | 0.625 |
| 29M50080R020WT | M5 | 20MM | 0.625 |
| 29M50080R025B | M5 | 25MM | 0.625 |
| 29M50080R025BL | M5 | 25MM | 0.625 |
| 29M50080R025GR | M5 | 25MM | 0.625 |
| 29M50080R025RD | M5 | 25MM | 0.625 |
| 29M50080R025WT | M5 | 25MM | 0.625 |
| 29M50080R040B | M5 | 40MM | 0.625 |
| 29M50080R040BL | M5 | 40MM | 0.625 |
| 29M50080R040GR | M5 | 40MM | 0.625 |
| 29M50080R040RD | M5 | 40MM | 0.625 |
| 29M50080R040WT | M5 | 40MM | 0.625 |
| 29M60100R012B | M6 | 12MM | 0.75 |
| 29M60100R012BL | M6 | 12MM | 0.75 |
| 29M60100R012GR | M6 | 12MM | 0.75 |
| 29M60100R012RD | M6 | 12MM | 0.75 |
| 29M60100R012WT | M6 | 12MM | 0.75 |
| Item Number | Screw Size | Screw Length | Head Dia. |
| 29M60100R016B | M6 | 16MM | 0.75 |
| 29M60100R016BL | M6 | 16MM | 0.75 |
| 29M60100R016GR | M6 | 16MM | 0.75 |
| 29M60100R016RD | M6 | 16MM | 0.75 |
| 29M60100R016WT | M6 | 16MM | 0.75 |
| 29M60100R020B | M6 | 20MM | 0.75 |
| 29M60100R020BL | M6 | 20MM | 0.75 |
| 29M60100R020GR | M6 | 20MM | 0.75 |
| 29M60100R020RD | M6 | 20MM | 0.75 |
| 29M60100R020WT | M6 | 20MM | 0.75 |
| 29M60100R025B | M6 | 25MM | 0.75 |
| 29M60100R025BL | M6 | 25MM | 0.75 |
| 29M60100R025GR | M6 | 25MM | 0.75 |
| 29M60100R025RD | M6 | 25MM | 0.75 |
| 29M60100R025WT | M6 | 25MM | 0.75 |
| 29M60100R040B | M6 | 40MM | 0.75 |
| 29M60100R040BL | M6 | 40MM | 0.75 |
| 29M60100R040GR | M6 | 40MM | 0.75 |
| 29M60100R040RD | M6 | 40MM | 0.75 |
| 29M60100R040WT | M6 | 40MM | 0.75 |
| 29M61100R012B | M6 | 12MM | 1 |
| 29M61100R012BL | M6 | 12MM | 1 |
| 29M61100R012GR | M6 | 12MM | 1 |
| 29M61100R012RD | M6 | 12MM | 1 |
| 29M61100R012WT | M6 | 12MM | 1 |
| Item Number | Screw Size | Screw Length | Head Dia. |
| 29M61100R016B | M6 | 16MM | 1 |
| 29M61100R016BL | M6 | 16MM | 1 |
| 29M61100R016GR | M6 | 16MM | 1 |
| 29M61100R016RD | M6 | 16MM | 1 |
| 29M61100R016WT | M6 | 16MM | 1 |
| 29M61100R020B | M6 | 20MM | 1 |
| 29M61100R020BL | M6 | 20MM | 1 |
| 29M61100R020GR | M6 | 20MM | 1 |
| 29M61100R020RD | M6 | 20MM | 1 |
| 29M61100R020WT | M6 | 20MM | 1 |
| 29M61100R025B | M6 | 25MM | 1 |
| 29M61100R025BL | M6 | 25MM | 1 |
| 29M61100R025GR | M6 | 25MM | 1 |
| 29M61100R025RD | M6 | 25MM | 1 |
| 29M61100R025WT | M6 | 25MM | 1 |
| 29M61100R040B | M6 | 40MM | 1 |
| 29M61100R040BL | M6 | 40MM | 1 |
| 29M61100R040GR | M6 | 40MM | 1 |
| 29M61100R040RD | M6 | 40MM | 1 |
| 29M61100R040WT | M6 | 40MM | 1 |
| 29M80125R012B | M8 | 12MM | 1 |
| 29M80125R012BL | M8 | 12MM | 1 |
| 29M80125R012GR | M8 | 12MM | 1 |
| 29M80125R012RD | M8 | 12MM | 1 |
| 29M80125R012WT | M8 | 12MM | 1 |
| Item Number | Screw Size | Screw Length | Head Dia. |
| 29M80125R016B | M8 | 16MM | 1 |
| 29M80125R016BL | M8 | 16MM | 1 |
| 29M80125R016GR | M8 | 16MM | 1 |
| 29M80125R016RD | M8 | 16MM | 1 |
| 29M80125R016WT | M8 | 16MM | 1 |
| 29M80125R020B | M8 | 20MM | 1 |
| 29M80125R020BL | M8 | 20MM | 1 |
| 29M80125R020GR | M8 | 20MM | 1 |
| 29M80125R020RD | M8 | 20MM | 1 |
| 29M80125R020WT | M8 | 20MM | 1 |
| 29M80125R025B | M8 | 25MM | 1 |
| 29M80125R025BL | M8 | 25MM | 1 |
| 29M80125R025GR | M8 | 25MM | 1 |
| 29M80125R025RD | M8 | 25MM | 1 |
| 29M80125R025WT | M8 | 25MM | 1 |
| 29M80125R040B | M8 | 40MM | 1 |
| 29M80125R040BL | M8 | 40MM | 1 |
| 29M80125R040GR | M8 | 40MM | 1 |
| 29M80125R040RD | M8 | 40MM | 1 |
| 29M80125R040WT | M8 | 40MM | 1 |
